316L Stainless Steel Body Construction.
EPDM Body and Seat gasket.
10 bar pressure rated.
-20 / + 130 deg C Temp rated.
Plain Butt Weld End connections to BS4825 Imperial.
Clamp together body.
This valve is designed for use on Food and Dairy applications.
The clamp together body construction allows easy access for cleaning and maintenance.
The valve comes with Plain O/D Imperial Weld Ends to BS4825 as standard. RJT, IDF, SMS, DIN and Clamp Ends are optional extras.
1/2” & 3/4” sizes are available on special order.
Please ask our sales office for details.
Available size range: 1” - 4”
For full details of our NTC High Performance Range, technical data, product images and more, visit http://ntcvalves.co.uk
